Sunix 2-Port High Speed Serial PCI Express Low Profile Card
• RS-232 interface • Low profile
NIVO#: 63377
Warranty: 1 year
Our price:
R 919.95
 (incl. VAT)
Availability  check now
Shipping time 2-4 business days
Shipping cost calculate
New to Online Shopping? Read our Shopping Guide.
things to do ...
Overview & Features top

2-port RS-232 High Speed PCI Express Low Profile Board

Description

SUNIX SER6437HL, PCI Express serial communication board meets the PCI Express Base Specification Revision 2.0. It is compatible with PCI Express x1, x2, x4, x8 and x16 lane Bus allowing it to be installed in any slim size PC-based system with low profile bracket structure. The majorities of today’s motherboard is not equipped with serial ports or only have one serial port. With SUNIX PCI Express serial board, users can add one serial port to their system, allowing them to use serial devices further. SUNIX SER6437HL card has 128-bytes onboard FIFO buffer and compatible with 16C950 UART specifications. It is designed with SUNIX UART controller, SUN2212 and as well built with many of SUNIX advanced features and technologies, making it the best solution for commercial and industrial automation applications.

Features

  • Expands two independent RS-232 serial ports with communication speeds up to 921.6Kbps.
  • With high reliable SUNIX SUN2212 native PCI Express 16C950 UART controller.
  • Designed to meet PCI Express Base Specification Revision 2.0.
  • Supports x1, x2, x4, x8, x16 (lane) PCI Express Bus connector keys.
  • On-chip hardware auto flow control to guarantee no data loss.
  • Built-in ± 15KV ESD protection for all serial signals meets IEC1000-4-2 standard.
  • Plug-n-Play, I/O address and IRQ assigned by BIOS.
  • Low profile bracket design idea for slim or portable PC.
  • Certified by CE, FCC, RoHS, and Microsoft WHQL approval.
  • Support Microsoft Windows, Linux, and DOS.
Specification top
General
Model
SER6437HL
Device Description
2-port RS-232 High Speed PCI Express Low Profile Board
Product Line
RS-232 Series
Product Type
Serial RS-232 board
Form Factor
Plug-in card

Connectivity
Wired/Wireless
Wired
Data Transfer Rate
50bps ~ 921.6Kbps
Connecting Interface Type
PCI Express
Expansion Interfaces Type
Serial Port
Ports
2

System Requirements
System Requirements
Windows Server: 2003 / 2008 / 2012 / 2016 (X64)
Windows Client: XP / Vista / 7 / 8.x / 10 (X86/X64)
Microsoft WHQL Windows
